Product Introduction

Application Scenarios

Stacker AGVs are commonly used for material handling between warehouses and production lines, as well as between different processes on a production line.

Product Features

▪ Optional SLAM or laser navigation modes

▪ Specialized AGV with a compact body and small footprint

▪ Load capacity range: 0.5-3t

▪ Repeatability accuracy up to ±5mm

▪ Optional automatic hole recognition and fork adjustment

▪ Multiple protections, safe and intelligent


Performance Parameters

Product ModelUnitCDD15-AGV4A5LICDD16 -AGV1C1LICDD16-AGV4B1LICDD16-AGV41ALICDD30-AGV4A1LI
Type/Stacking type
Navigation method/SLAMSLAMLaserSLAMSLAM
Rated loadkg15001600160016003000
Maximum lifting heightmm20003600300030002500
Maximum travel speed (full load/no load)km/h5/54/44/44/45/5
Minimum turning radiusmm12181340134016061747
Right-angle stacking width (pallet 1200*1200)mm22002343261528533084
Positioning accuracymm±5
Communication method/5G/WIFI
Battery capacity (standard)V/Ah24/10024/17324/17324/20248/173
Vehicle weight (including battery)kg8501090111010901395
Standard vehicle body dimensions (length, width, height)mm1675×856×19601832×1010×22851832×1010×21772168×925×19302070×1035×2610
