Product Introduction

Application Scenarios

Three-point balance-weight AGVs are commonly used for loading, unloading, and transporting materials indoors and outdoors.


Product Features

▪ Laser navigation, high positioning accuracy

▪ Higher vehicle maneuverability and passability

▪ 3.5-ton load capacity, no load reduction at 3m

▪ Front-wheel drive, powerful

▪ Large-capacity lithium battery, long battery life

▪ Side-mounted automatic charging, integrated charger

▪ Double-sided opening hood, more convenient maintenance

▪ Rubber tires, easy switching between indoor and outdoor operations

▪ Multiple protections, intelligent safety


Performance Parameters

Product ModelUnitCPD10SQ-AGV1A1LICPD16-AGV11ALICPD16-AGV41ALICPD20SQ-AGV001CPD35SQ-AGV
Type/Counterweight Type
Navigation Method/Laser
Rated Loadkg10001600160020003500
Maximum Lifting Heightmm36003600360033003000
Maximum Travel Speed (Full Load/No Load)km/h5/54/44/45/56/6
Minimum Turning Radiusmm12501805180517411920
Right Angle Stacking Width (1200*1200 Pallet)mm28403578357836173872
Positioning Accuracymm±5
Communication Method/5G/WIFI
Battery Capacity (Standard)V/Ah24/28024/20224/20248/40480/404
Vehicle Weight (Including Battery)kg24502050198537005300
Standard Vehicle Dimensions (Length, Width, Height, Including Forks)mm2430×1296×25002972×1015×17802972×1015×17803286×1170×24573421×1223×2430
